The base class of every user interface element. More...

Inheritance diagram for Widget:

Classes
class	TopLevelCollection

class	WidgetCollection

Public Member Functions
T?	FindParent< T > ()

IEnumerable< Widget >	EnumerateChildren ()

bool	ContainsChild (Widget? widget)

bool	BelongsToParent (Widget widget)

void	InvalidateClipping (bool recursive=false)

void	InvalidateGeometry (bool invalidateChildren=false)

IVisualStyle?	GetVisualStyleOverride ()
	Walks up the widget tree from this widget to the top-level, returning the first visual style override that isn't null. If no widgets in the path override the global visual style, then null will be returned.

bool	IsInsideClipRegion (Point point)

T	GetCustomProperty< T > ()

void	SetCustomProperty< T > (T newValue)

T	GetCustomProperties< T > ()

IFontFamily	GetFont (PresetFontFamily family)

void	GiveFocus ()

readonly struct	BackgroundStyleProperties (Texture2D? fillImage, Color fillColor, int strokeThickness, Color strokeColor, Rounding rounding)

virtual void	Inspect (IInspector inspector)

void	InvalidateOwnLayout ()

void	Invalidate (InvalidationMode invalidationMode)

void	InvalidateLayout ()

void	UpdateLayout (IGuiContext context, LayoutRect availableSpace)

Point	GetCachedContentSize (Point availableSize)

Protected Member Functions
virtual void	RebuildClippingZone (GeometryHelper geometry)

virtual void	RebuildGeometry (GeometryHelper geometry)

virtual void	BeforeRender ()

virtual bool	ShouldRenderChild (Widget childWidget)

virtual void	OnAddedToParent ()

virtual void	OnRemovedFromParent ()

virtual void	OnParentChanged ()

bool	GetTextColor (ref Color color, Color? fallbackColor=null)

void	GetThemeProperties< TThemeProperties > (ref TThemeProperties properties, InvalidationMode invalidationMode=InvalidationMode.LayoutAndGeometry)

virtual void	ArrangeChildren (IGuiContext context, LayoutRect availableSpace)

virtual Point	GetContentSize (Point availableSize)

bool	SendSignal< TSignal > (TSignal signal, SignalDirection direction=SignalDirection.Up)
	Send a signal of type TSignal from this widget.

Properties
int	ChildCount `[get]`

string?	Name `[get, set]`

ulong	ScreenReaderId `[get]`

ScreenReaderNode	ScreenReaderNode `[get]`

bool	IsLayoutValid `[get]`

ulong	UniqueId `[get]`

Matrix4x4	ComputedTransformMatrix `[get]`

AccessibilityRole	Role `[get, set]`
	Gets or sets a AccessibilityRole value representing the role of this Widget shown to accessibility software. Screen readers use this value to figure out what kind of UI element the widget is.

Widget?	LabelledBy `[get, set]`

string	RoleDescription `[get, set]`

string	AccessibleLabel `[get, set]`
	Gets or sets the accessible label for this widget. This string is read aloud by screen readers.

bool	ClipSelf `[get, set]`

Quaternion	Rotation `[get, set]`

Vector3	Scale `[get, set]`

Point	PositionOffset `[get, set]`

Point	ComputedPositionOffset `[get]`

BackgroundStyleProperties	BackgroundStyle `[get, set]`

IWidgetEffect?	RenderEffect `[get, set]`

bool	IsFocused `[get]`

bool	IsChildFocused `[get]`

LayoutRect?	ClippedContentArea `[get]`

ClippingMode	ClippingMode `[get, set]`

bool	Enabled `[get, set]`

float	RenderOpacity `[get, set]`

bool	HierarchyEnabled `[get]`

float	ComputedOpacity `[get]`

IVisualStyle?	VisualStyleOverride `[get, set]`

Widget?	Parent `[get]`

Widget?	Root `[get]`

virtual ? GuiManager	GuiManager `[get]`

IOrderedCollection< Widget >	InternalChildren `[get]`

Widget?	ContextMenuWidget `[get, set]`
	Gets or sets a widget to be shown when the user right-clicks this widget or one of its children.

bool	IsVisible `[get]`

Visibility	Visibility `[get, set]`

LayoutRect	PaintArea `[get]`

Padding	Margin `[get, set]`

Padding	Padding `[get, set]`

int	MinimumWidth `[get, set]`

int	MinimumHeight `[get, set]`

int	MaximumWidth `[get, set]`

int	MaximumHeight `[get, set]`

Point	MinimumSize `[get, set]`

Point	MaximumSize `[get, set]`

HorizontalAlignment	HorizontalAlignment `[get, set]`

VerticalAlignment	VerticalAlignment `[get, set]`

LayoutRect	LayoutArea `[get]`

Widget	LayoutRoot `[get, protected set]`

PopoverLocationPreference	PopoverLocation `[get, set]`

PopoverContent?	PopoverContent `[get, set]`

Events
static ? Action< Widget, LayoutRect >	WidgetRepainting = null

Detailed Description

The base class of every user interface element.

Member Function Documentation

◆ ArrangeChildren()

virtual void ArrangeChildren	(	IGuiContext	context,
		LayoutRect	availableSpace )

inlineprotectedvirtual

Reimplemented in WidgetView, SplitView, MenuOverlay, ViewportWidget, and TreeView.

◆ BeforeRender()

virtual void BeforeRender ( )

inlineprotectedvirtual

Reimplemented in MenuBarItem, and MenuItem.

◆ FindParent< T >()

T? FindParent< T > ( )

inline

Type Constraints

T

:

Widget

◆ GetContentSize()

virtual Point GetContentSize ( Point availableSize )

inlineprotectedvirtual

Reimplemented in SplitView, MenuOverlay, ColorButton, ColorSlider, and TreeView.

◆ GetCustomProperties< T >()

T GetCustomProperties< T > ( )

inline

Type Constraints

T

:

CustomPropertyObject

◆ GetCustomProperty< T >()

T GetCustomProperty< T > ( )

inline

Type Constraints

T

:

struct

◆ GetThemeProperties< TThemeProperties >()

void GetThemeProperties< TThemeProperties >	(	ref TThemeProperties	properties,
		InvalidationMode	invalidationMode = InvalidationMode::LayoutAndGeometry )

inlineprotected

Type Constraints

TThemeProperties

:

struct

◆ GetVisualStyleOverride()

IVisualStyle? GetVisualStyleOverride ( )

inline

Walks up the widget tree from this widget to the top-level, returning the first visual style override that isn't null. If no widgets in the path override the global visual style, then null will be returned.

Returns: The visual style override for this widget or one of its parents, or null if there are no overriding widgets.

◆ OnAddedToParent()

virtual void OnAddedToParent ( )

inlineprotectedvirtual

Reimplemented in WidgetView, PropertyEditorWidget< TPropertyValue >, AssetBrowser, Hierarchy, PlayView, ColorPicker, and MenuBarItem.

◆ OnRemovedFromParent()

virtual void OnRemovedFromParent ( )

inlineprotectedvirtual

Reimplemented in PlayView, and MenuBarItem.

◆ RebuildClippingZone()

virtual void RebuildClippingZone ( GeometryHelper geometry )

inlineprotectedvirtual

Reimplemented in EditorPanel.

◆ RebuildGeometry()

virtual void RebuildGeometry ( GeometryHelper geometry )

inlineprotectedvirtual

Reimplemented in WidgetView, EditorWidget, EditorPanel, EditorSplashScreenWidget, ViewportWidget, ColorButton, ColorSlider, Menu, MenuBarItem, and MenuItem.

◆ SendSignal< TSignal >()

bool SendSignal< TSignal >	(	TSignal	signal,
		SignalDirection	direction = SignalDirection::Up )

inlineprotected

Send a signal of type TSignal from this widget.

Parameters

signal	The signal to send.
direction	A value indicating where to send the signal.

Template Parameters

TSignal The type of signal to send.

Returns: True if the signal was handled, false otherwise.

◆ SetCustomProperty< T >()

void SetCustomProperty< T > ( T newValue )

inline

Type Constraints

T

:

struct

The documentation for this class was generated from the following files:

/home/ritchie/Projects/toolbox/src/Ritchie.Toolbox/Widgets/Widget.Collections.cs
/home/ritchie/Projects/toolbox/src/Ritchie.Toolbox/Widgets/Widget.cs
/home/ritchie/Projects/toolbox/src/Ritchie.Toolbox/Widgets/Widget.Layout.cs
/home/ritchie/Projects/toolbox/src/Ritchie.Toolbox/Widgets/Widget.Popovers.cs
/home/ritchie/Projects/toolbox/src/Ritchie.Toolbox/Widgets/Widget.Debugging.cs
/home/ritchie/Projects/toolbox/src/Ritchie.Toolbox/Widgets/Widget.Signals.cs
